Semi Automatic Liquid Filling Machine 0.6-0.8MPa Horizontal Durable
Product Details:
| Place of Origin: | China |
| Brand Name: | LIANHE |
| Certification: | CE , ISO , SGS , TUV |
| Model Number: | LGJ-W |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Contact Us |
| Packaging Details: | Normally packaged in wooden case or wrapping film, also can be customized |
| Delivery Time: | 20-30 working days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 60 Sets per Month |
|
Detail Information |
|||
| Filling Principle: | Atmospheric Pressure | Air Supply: | 0.6-0.8MPa |
|---|---|---|---|
| Driven Type: | Piston | Structure: | Vertical Or Horizontal |
| Material: | Stainless Steel 304 & 316 | Filling Accuracy: | ±0.1% |
| High Light: | 0.6MPa Liquid Filling Machine,0.8MPa Horizontal Liquid Filling Machine,Horizontal Semi Automatic Liquid Filling Machine |
||
Product Description
Semi Automatic Liquid Filling Machine Horizontal Shampoo Detergent Filler
Product Description:
The semi-auto self-suction filling machine (pneumatic driven) suitable for filling from the water (containing particles) to various viscosity products cream, suitable for daily chemical, medicine, food, pesticide and other industries. Suitable for water, honey, yogurt, fruit juice, shampoo, shower gel Liquid, gear oil, coffee, ink, liquid eye shadow, tea, food pigment,hand washing liquid, lotion, milk, liquid soap, syrup, food oil, etc.
Product Parameters:
| Model | Filling Volume | Filling Precision | Air Consumption | Productivity |
| LGJ-W-15 | 5-150ml | ±0.1% | 23 L/min | 20-50 bot/min |
| LGJ-W-25 | 10-250ml | ±0.1% | 30 L/min | 20-50 bot/min |
| LGJ-W-50 | 30-500ml | ±0.1% | 44 L/min | 20-50 bot/min |
| LGJ-W-100 | 60-1000ml | ±0.1% | 87 L/min | 20-50 bot/min |
| LGJ-W-250 | 250-2500ml | ±0.1% | 160 L/min | 20-50 bot/min |
| LGJ-W-500 | 500-5000ml | ±0.1% | 300 L/min | 20-50 bot/min |
| The parameters are for reference only, the products can be customized | ||||
Product Features:
1. The series machine is compact and reasonable in design and beautiful and decent in appearance.
2.The machine is made of imported mechanical parts ,pistons,cylinders,stainless steel and PTFE.
3.The machine is light and convenient with brand new horizontal design and automatic material drawing.
4.The machine is suitable for filling ointment products in the industries such as ointment,shampoo,syrup and fruit juice etc.
5.Simple to operate, easy to clean, and appliance widely, for kinds of user, it has a great practicability and efficiency.
6.It can work automatically or controlled by an operation pedal.
7. Full-pneumatic design, all elements are controlled by compressing air. So it can meet explosion-proof requirement and has high security.
8. No static electricity, no need to connect to earthing (grounding).
9. Stainless steel piston housing and solid volume-control device make high precision to ±1% (as per max filling volume).
Filling nozzle:
1. Filling nozzle is made of 304 stainless steel.
2. It can be customized for anti-drawing, anti-drip design and 316 stainless steel.
3. Different size 5mm, 8mm,10mm or customized.
Filling volume adjustment system:
The stroke of the cylinder can be controlled by the reed switch. The filling volume can be adjusted, You can adjust the intake air
cylinder to achieve rapid or slow filling.
High quality cylinder:
1. High precision
2. Stable work
3. Durable
Control System:
1. E-stop Button: Safety switch, emergency braking.
2. Manual / Auto Knob: The machine can be foot-operated or auto mode control filling.
3. Air pressure adjustment knob and barometer: Pull up the knob to adjust the air pressure.
Product Details:
Our Servers:
We provide Turn-key project service to customer.
1. Factory Layout design;
2. Factory Decoration based on GMP standard;
3. Formula of products;
4. Raw material etc;
5. Machine design, whole production line from A to Z;
6. Shipping service, FOB, CFR, CIF etc;
7. Installation service. Training service, Mainte.
