SUS316L High Shear Emulsifier Mixer Liquid Detergent Making Machine With Heating And Homogenizer
Product Details:
| Place of Origin: | China |
| Brand Name: | LIANHE |
| Certification: | TUV, CE, SGS, GMP |
| Model Number: | PMC-1000L, PMC-2000L |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Plywood Case / Bubble Film Packaging |
| Delivery Time: | 25 Working Days |
| Payment Terms: | T/T, D/A, L/C |
| Supply Ability: | 20 Sets Per Month |
|
Detail Information |
|||
| Available Capacity: | 5L-6000L | Heating Method: | Electric Heating / Steam Heating |
|---|---|---|---|
| Motor: | ABB Or SIEMENS | Mixing Speed: | 0-65 R.p.m |
| Homogenizer Speed: | 0-3600 R.p.m | Warranty: | 1 Year, Service Support All The Time |
| Material: | All Product Contact Part Are Made Of SUS316L | Application: | Liquid Detergent/chemcial/gel/shampoo/hand Sanitizerr |
| Mixing Method: | One Way Or Two Way Mixing With Teflon Scraper | ||
| High Light: | SUS316L High Shear Emulsifier Mixer,Liquid Detergent High Shear Emulsifier Mixer,ABB Motor High Shear Emulsifier Mixer |
||
Product Description
2022 High Shear Emulsifier Mixer Liquid Detergent Making Machine with Heating and Homogenizer
Brief Introduction:
2022 High Shear Emulsifier Mixer Liquid Detergent Making Machine with Heating and Homogenizer is for producing liquid washing products like bath shower, dish washing, hand washing, lotion, liquid soap, detergent, shampoo, hand sanitizer gel, wax, sauce, juice, ketchup, etc.
Complex wall scraping blending paddle is suitable to every kind of complicated recipe and achieve optimizing result;
Polytetrafluoroethylene scraping board cater to body of blending groove and scrape out viscosity material on the wall of the tank;
Mightiness balance isotactic curve rotor is matched with stator with corresponding structure to realize liquid high-capability cut,rubbing,centrifugal to make sure exquisite and slick product; boiler body and pipe surface mirror polishing 300EMSH (sanitation grade) accords with Daily Chemical and GMP regulation.
Warranty: One year since the date of installation. If there is any wearing part be broken within the warranty and isn’t caused by un-properly operation, then the Seller would offer the new parts for free.New Model High Efficient Tilting Vacuum Emulsifying Mixer Machine For Cosmetic
Inspection: The buyer will do the machine inspection when the machines are ready.
Machine Installation or Fixing: If Buyer requires Seller’s engineer to install or fix the machine locally in due course, the Buyer should pay the round air ticket cost and arrange the hotel accommodation as well as the means for Seller’s engineer.small bus
Technical Parameter:
| Capacity (L) | Homogenizer | Agitator | Vacuum pump | Heating system | ||||
| power (kw) | speed (rpm) | power (kw) | speed (rpm) | power (kw) | Limit vacuum | Electric heating (kw) | Steam heating (Mpa) | |
| 5 | 0.55 | 0-3600 | 0.4 | 0-65 | 0.37 | -0.1 | 6 | 0.2 |
| 10 | 1.1 | 0-3600 | 0.55 | 0-65 | 0.37 | -0.1 | 6 | 0.2 |
| 20 | 1.5 | 0-3600 | 0.55 | 0-65 | 0.37 | -0.1 | 9 | 0.2 |
| 50 | 3 | 0-3600 | 0.75 | 0-65 | 0.75 | -0.1 | 12 | 0.2 |
| 100 | 4 | 0-3600 | 1.5 | 0-65 | 1.5 | -0.1 | 24 | 0.2 |
| 200 | 5.5 | 0-3600 | 1.5 | 0-65 | 2.2 | -0.1 | 28 | 0.2 |
| 300 | 7.5 | 0-3600 | 3 | 0-65 | 2.2 | -0.1 | 32 | 0.2 |
| 500 | 11 | 0-3600 | 4 | 0-65 | 4 | -0.1 | 50 | 0.2 |
| 1000 | 15 | 0-3600 | 5.5 | 0-65 | 4 | -0.1 | 54 | 0.2 |
| 2000 | 18.5 | 0-3600 | 7.5 | 0-65 | 5.5 | -0.1 | recommend steam heating | 0.2 |
| 5000 | 22.5 | 0-3600 | 15 | 0-65 | 7.5 | -0.1 | 0.2 | |
| The parameters are for reference only, all the machines can be customized according to your needs. | ||||||||
Advantages:
1. Keep the equipment looks clean, no watermarks, smooth
2. Keep equipment clean, after finished product should be cleaned with hot water as soon as possible
3. Check on the homogeneous blade usually, Are there loose screws
4. Homogenizer into the water whether the flow, the water solenoid valve is working properly
5. Check the mixing gear regularly adequacy of the grease, any abnormal sound
6. We can supply the whole production line
Features:
*Material of the tank: SS304, SS316, SS316L.
*The homogenize can be installed at the top or bottom of the tank.
*The type of the agitator(stirrer) can be adjusted.
*Basic structure: Tank body, motor, mixing stireer(agitator), manhole, support legs.
*Optional function: Sight glass, heating and cooling jacket, thermometer, etc.
*Tank supported:Movable caster, working platform, support leg optional.
Application Product:
1. Daily Chemical & Cosmetics Industry:
such as baby cream, skin cream face cream, shaving cream, shaving cream, cream shampoo, toothpaste, cold cream, sunscreen cream,face cleanser, moisture cream, detergent, shampoo etc;
2. Food Industry:
Sauce, cheese, oral, nutrition, infant food, chocolate, sugar and so on., tomato paste etc;
3. Pharmacy Industry:
Latex, emulsions, salves (ointments), oral syrup, liquid. etc;
4. Chemical Industry:
Latex, sauce, saponification products, paints, coatings, resins, adhesives, lubricants and the like.
C
The High Shear Lotion Homogenizer Emulsifier Mixer With Circulation System is for producing liquid washing products like bath shower, dish washing, hand washing, lotion, liquid soap, detergent, shampoo, hand sanitizer gel, wax, sauce, juice, ketchup, etc.
Complex wall scraping blending paddle is suitable to every kind of complicated recipe and achieve optimizing result;
Polytetrafluoroethylene scraping board cater to body of blending groove and scrape out viscosity material on the wall of the tank;
Mightiness balance isotactic curve rotor is matched with stator with corresponding structure to realize liquid high-capability cut,rubbing,centrifugal to make sure exquisite and slick product; boiler body and pipe surface mirror polishing 300EMSH (sanitation grade) accords with Daily Chemical and GMP regulation.
