High Shear Lab Emulsifying Heating Mixer 5L 10L Homogenizer Vacuum Emulsifier Tank
Product Details:
| Place of Origin: | China |
| Brand Name: | LIANHE |
| Certification: | TUV, CE, SGS, GMP |
| Model Number: | VME-A-10L |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Plywood Case / Bubble Film Packaging |
| Delivery Time: | In stock |
| Payment Terms: | T/T, D/A, L/C |
| Supply Ability: | 20 Sets Per Month |
|
Detail Information |
|||
| Available Capacity: | 5L-6000L | Tank Structure: | 3 Layers Of Steel, 2 Jackets |
|---|---|---|---|
| Material: | SUS316L/SUS304/SUS304 | Heating Method: | Electric Heating / Steam Heating |
| Cooling: | Tap Water / Ice Water Cooling | Mixing Method: | One Way Or Two Way Mixing With Teflon Scraper |
| Mixing Speed: | 0-65 R.p.m | Homogenizer Speed: | 0-3600 R.p.m |
| Control: | PLC&Touch Screen / Button | ||
| High Light: | High Shear Lab Emulsifying Heating Mixer,Lab Emulsifying Heating Mixer 5L,5L High Shear Emulsifier Mixer |
||
Product Description
High Shear Lab Emulsifying Machine Mixer 5L 10L Homogenizer Vacuum Emulsifier Tank
Brief Introduction:
Total volume: 13L, Working volume: 10L
It is especially suitable for cosmetic research and development centers, or laboratory use, for testing, proofing, and pilot testing of various pastes, creams, water emulsions, liquids, and gels.
1. The machine has triple blender, hydraulic lift cover, high-speed homogeneity blender (Speed is 0-3600r/min, frequency speed regulation) and low-speed scraper blender (Speed is 0-65r/min, frequency speed regulation).
Fast high shear emulsificatio is used in the homogenizer part, which can scrape in a low speed and automatically blend and snuggle up to the bottom and wall of boiler.
The machine draws powder material by the way of vacuum in order to prevent the powder flying. The whole working procedure is operated in the condition of vacuum in order to prevent the material coming into being bubble after high-speed blending and reach the request of sanitation and asepsis. CIP cleaning system is equipped in this system. The contact part of vessel and material is made from SUS316L material.
The machine is made completely according to the GMP request, which is the most advanced and most perfect cream production equipment.
2. The machine is specially designed adopting germany technology of according to the cosmetic and ointment production technology.
The machine is made up of pretreatment boiler, vacuum emulsification blending boiler, vacuum pump, hydraulic system and worktable.
3. The machine has easy operation, steady capability, good homogeneity, high efficiency, reasonable structure, small volume and high automation level and easily clean.
Technical Parameter:
| Capacity (L) | Homogenizer | Agitator | Vacuum pump | Heating system | ||||
| power (kw) | speed (rpm) | power (kw) | speed (rpm) | power (kw) | Limit vacuum | Electric heating (kw) | Steam heating (Mpa) | |
| 5 | 0.55 | 0-3600 | 0.4 | 0-65 | 0.37 | -0.1 | 6 | 0.2 |
| 10 | 1.1 | 0-3600 | 0.55 | 0-65 | 0.37 | -0.1 | 6 | 0.2 |
| 20 | 1.5 | 0-3600 | 0.55 | 0-65 | 0.37 | -0.1 | 9 | 0.2 |
| 50 | 3 | 0-3600 | 0.75 | 0-65 | 0.75 | -0.1 | 12 | 0.2 |
| 100 | 4 | 0-3600 | 1.5 | 0-65 | 1.5 | -0.1 | 24 | 0.2 |
| 200 | 5.5 | 0-3600 | 1.5 | 0-65 | 2.2 | -0.1 | 28 | 0.2 |
| 300 | 7.5 | 0-3600 | 3 | 0-65 | 2.2 | -0.1 | 32 | 0.2 |
| 500 | 11 | 0-3600 | 4 | 0-65 | 4 | -0.1 | 50 | 0.2 |
| 1000 | 15 | 0-3600 | 5.5 | 0-65 | 4 | -0.1 | 54 | 0.2 |
| 2000 | 18.5 | 0-3600 | 7.5 | 0-65 | 5.5 | -0.1 | recommend steam heating | 0.2 |
| 5000 | 22.5 | 0-3600 | 15 | 0-65 | 7.5 | -0.1 | 0.2 | |
| The parameters are for reference only, all the machines can be customized according to your needs. | ||||||||
Unique Features:
ØAll stainless steel interlayer constant temperature thermal insulation reaction kettle
ØHumanized flipping function
ØThe equipment is highly modularized, and various systems can be selected
ØHigh-speed motor imported from Germany, long-life design, stable operation
Ø The structure of the whole machine is reasonably designed, the material selection is excellent, and the emulsification system is perfect.
ØStepless speed regulation, the highest speed can reach 5,000rpm, providing you with a shearing line speed of 27m/s
ØMeet your different working environments (closed, open, normal pressure, vacuum)
ØOverload protection, double protection insulation, to give you security
ØThe working head is made of stainless steel, which is reusable and conforms to GMP hygiene standards
ØEquipment modular design, any system can be flexibly combined. Quick disassembly work head.
Optional Configuration:
Ø Reactor system (stainless steel and glass optional)
Ø Emulsifying system (optional for emulsifying and homogenizing head)
ØMixing system (digital display timing mixer optional)
ØTemperature control system (temperature probe optional)
Ø Lifting system (pneumatic assist and electric lift optional)
ØVacuum system (vacuum pump)
Ø Heating system (water bath or oil bath)
ØOnline monitoring system
Application Product:
1) Cosmetics industry: skin care cream, shaving cream, shampoo cream, toothpaste, cold cream, cold sun cream, facial cleanser, nutrient dense, detergent, shampoo, essence, moisturizing cream, hand cream, private gel gel, aloe vera gel, etc.
2) Daily chemicals: laundry detergent, hand sanitizer, toilet cleaning, car glass water, etc.
3) Pharmaceutical industry: latex, emulsion, ointment (ointment), oral syrup, oral liquid, etc.
4) Food industry: sauce, cheese, nutrient solution, baby food, chocolate, sugar, etc.
5) Chemical industry: latex, sauce, saponification products, paints, coatings, resins, adhesives, lubricants, etc.
