Multifunctional Detergent Liquid Mixer Machine 1000L 4KW Practical
Product Details:
| Place of Origin: | China |
| Brand Name: | LIANHE |
| Certification: | CE, TUV, SGS, GMP |
| Model Number: | PMC-2000L |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Plywood Case / Bubble Film Packaging |
| Delivery Time: | 30 Working Days |
| Payment Terms: | T/T, D/A, L/C |
| Supply Ability: | 20 Sets Per Month |
|
Detail Information |
|||
| Available Capacity: | 30L To 6000L | Tank Structure: | 3 Layers Of Steel, 2 Jacket |
|---|---|---|---|
| Material: | SUS316L/SUS304/SUS304 | Heating Method: | Electric Heating / Steam Heating |
| Cooling: | Water Cooling | Mixing Method: | One Way Or Two Way Mixing With Teflon Scraper |
| Mixing Speed: | 0-65RPM | Homogenizer Speed: | 3000RPM |
| High Light: | Multifunctional Detergent Liquid Mixer Machine,1000L Detergent Liquid Mixer Machine,4KW Liquid Detergent Mixer Machine |
||
Product Description
1000L High Shear Liquid Mask Making Machine Heating Tank Shampoo Mixer Emulsifier
Brief Introduction:
The mixing tank has the functions of stirring and mixing liquid or powder, and belongs to mass production products; and can be supplemented by dispersing, emulsifying, heating and cooling functions to meet the needs of different production processes; it can run for a long time, with stable operation and low noise , Simple operation, strong adaptability, is an ideal multi-functional equipment such as stirring and dispersing.
【Material viscosity】: ≤500.000cps
【Production capacity】: 30-50000L
【Application】: It is suitable for dispersing and mixing products in industries such as biology, medicine, food, coatings, inks, adhesives, dyes and pesticides.
【Applicable materials】: Various slurries with material viscosity below 500,000cps and solid content below 60%.
Technical Parameter:
| Model | Capacity (L) | Agitator | Homiogenizer | Heating system | |||
| power (kw) | speed (rpm) | power (kw) | speed (rpm) | Electric heating (kw) | Steam heating (Mpa) | ||
| PMC-50 | 50 | 0.75 | 0-65 | 3 | 3000 | 6 | Steam heating energy conservation and environmental protection, selected according to need |
| PMC-100 | 100 | 1.5 | 0-65 | 4 | 3000 | 9 | |
| PMC-150 | 150 | 1.5 | 0-65 | 4 | 3000 | 12 | |
| PMC-200 | 200 | 1.5 | 0-65 | 4 | 3000 | 12 | |
| PMC-300 | 300 | 1.5 | 0-65 | 5.5 | 3000 | 18 | |
| PMC-500 | 500 | 2.2 | 0-65 | 7.5 | 3000 | 27 | |
| PMC-1000 | 1000 | 4 | 0-65 | 11 | 3000 | 36 | |
| PMC-1500 | 1500 | 5.5 | 0-65 | 15 | 3000 | 45 | |
| PMC-2000 | 2000 | 7.5 | 0-65 | 15 | 3000 | recommend steam heating | |
| PMC-3000 | 3000 | 11 | 0-65 | 15 | 3000 | ||
| PMC-5000 | 5000 | 11 | 0-65 | 22 | 3000 | ||
| The parameters for reference only, all the machines can be customized accordingly. | |||||||
Application Product:
1) Cosmetics industry:
Skin care cream, shaving cream, shampoo, toothpaste, cold cream, cold sun cream, facial cleanser, nutrient dense, detergent, shampoo, serum, moisturizing cream, hand cream, etc.
2) Daily chemical:
Laundry liquid, hand sanitizer, detergent, toilet cleaning, car glass water, etc.
3) Pharmaceutical industry:
Latex, cream, ointment (ointment), oral syrup, oral liquid, etc.
4) Food industry:
Sauce, cheese, nutrient solution, oil, baby food, chocolate, sugar, etc.
5) Chemical industry:
Latex, sauces, saponified products, paints, coatings, resins, adhesives, lubricants, etc.
Features:
The mixing tank can be equipped with 1-2 high-speed dispersers, emulsifiers, dispersers, and emulsification equipment as required.
The rotating speed can be as high as 3000rpm and the linear speed is more than 20m/s, which can quickly and uniformly disperse the powder into the liquid material. Due to the high shear force, the material is uniformly dispersed, forming a good suspension effect, and the state is stable.
Easy maintenance and cleaning.
The agitator and the main shaft are fixed with bolts, which is convenient to move and disassemble.
Strong non-standard, various types of non-standard products can be customized, such as explosion-proof type, airtight vacuum type, wall scraping type, multi-functionality, etc.
This machine can be customized 316L stainless steel or anti-corrosion spray treatment according to customer requirements.
