3T 65RPM Small Shampoo Making Machine , Rustproof Soap Making Mixer Machine
Product Details:
| Place of Origin: | China |
| Brand Name: | LIANHE |
| Certification: | CE, TUV, SGS, GMP |
| Model Number: | PMC-3000L |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Plywood Case / Bubble Film Packaging |
| Delivery Time: | 30 Working Days |
| Payment Terms: | T/T, D/A, L/C |
| Supply Ability: | 20 Sets Per Month |
|
Detail Information |
|||
| Available Capacity: | 30L To 6000L | Tank Structure: | 3 Layers Of Steel, 2 Jacket |
|---|---|---|---|
| Material: | SUS316L/SUS304/SUS304 | Heating Method: | Electric Heating / Steam Heating |
| Cooling: | Water Cooling | Mixing Method: | One Way Or Two Way Mixing With Teflon Scraper |
| Mixing Speed: | 0-65RPM | Homogenizer Speed: | 3000RPM |
| High Light: | 3T Small Shampoo Making Machine,65RPM Small Shampoo Making Machine,Rustproof Soap Making Mixer Machine |
||
Product Description
3T High Shear Shampoo Mixer Heating Emulsifier Tank for Liquid Soap
Brief Introduction:
Our Mixers is specially used for stirring, mixing, blending and homogenizing materials.
The stainless steel mixing tank can be designed and configured according to the requirements of the production process and can be standardized and humanized. The mixing tank can realize feeding control, discharging control, mixing control and other manual automatic control during the mixing process. The structure of the high shear mixer tank is composed of a mixing tank body, a stirring tank cover, a stirrer, a support, a transmission device, a shaft sealing device, etc., and a heating device or a cooling device can also be configured according to the process requirements.
The materials selected for the mixing tank body, stirring tank cover, agitator, and shaft seal can be made of carbon steel or stainless steel according to different process requirements.
The tank body and the mixing tank cover can be connected by flange sealing or welding.
The tank body and stirring tank cover can open process pipe holes such as feeding, discharging, observation, temperature measurement, pressure measurement, steam fractionation, and venting according to the process requirements.
The upper part of the mixing tank cover is equipped with a transmission device (motor or reducer), and the agitator in the mixing tank is driven by the transmission shaft.
The shaft seal device can adopt various forms such as mechanical seal or packing, labyrinth seal (determined according to user needs).
Technical Parameter:
| Model | Capacity (L) | Agitator | Homiogenizer | Heating system | |||
| power (kw) | speed (rpm) | power (kw) | speed (rpm) | Electric heating (kw) | Steam heating (Mpa) | ||
| PMC-50 | 50 | 0.75 | 0-65 | 3 | 3000 | 6 | Steam heating energy conservation and environmental protection, selected according to need |
| PMC-100 | 100 | 1.5 | 0-65 | 4 | 3000 | 9 | |
| PMC-150 | 150 | 1.5 | 0-65 | 4 | 3000 | 12 | |
| PMC-200 | 200 | 1.5 | 0-65 | 4 | 3000 | 12 | |
| PMC-300 | 300 | 1.5 | 0-65 | 5.5 | 3000 | 18 | |
| PMC-500 | 500 | 2.2 | 0-65 | 7.5 | 3000 | 27 | |
| PMC-1000 | 1000 | 4 | 0-65 | 11 | 3000 | 36 | |
| PMC-1500 | 1500 | 5.5 | 0-65 | 15 | 3000 | 45 | |
| PMC-2000 | 2000 | 7.5 | 0-65 | 15 | 3000 | recommend steam heating | |
| PMC-3000 | 3000 | 11 | 0-65 | 15 | 3000 | ||
| PMC-5000 | 5000 | 11 | 0-65 | 22 | 3000 | ||
| The parameters for reference only, all the machines can be customized accordingly. | |||||||
Application Product:
1. Cosmetics industry: skin care cream, shaving cream, shampoo, toothpaste, cold cream, cold sun cream, facial cleanser, nutrient dense, detergent, shampoo, hair cream, conditioner, essence, moisturizing cream, Hand cream, etc.
2. Daily chemical: laundry detergent production, hand sanitizer, toilet cleaning, car glass water, etc.
3. Pharmaceutical industry: latex, emulsion, ointment (ointment), oral syrup, oral liquid, etc.
4. Food industry: sauce, cheese, nutrient solution, baby food, chocolate, sugar, etc.
Features:
- The all-around wall Teflon scraping mixing adopts the frequency inverter for speed adjustment, so it can be adjusted to make different products with different manufacturing requirements.
- The diversified high-speed homogenizer can powerfully mix solid, oil and liquid raw materials and can rapidly dissolve many indissoluble materials such as AES, AESA, LSA,etc.
- The pot body is welded by SUS316 three-layer stainless steel plate.the tank body and the pipes adopt 5 times mirror polishing, which fully conforms to GMP standard requirements.
- The motor for homogenizer and mixing paddle, we only use Siemens or ABB, with higher quality, better stability and longer service life.
- All main parts of the machine are adopted with international brands, such as Delta, Schneider, Siemens, Omron, etc.
