Chemical Liquid Soap Homogenizer Detergent Mixing Machine Lotion Emulsifier Mixer
Product Details:
| Place of Origin: | China |
| Brand Name: | LIANHE |
| Certification: | TUV, CE, SGS, GMP |
| Model Number: | PMC-1000L, PMC-2000L |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Plywood Case / Bubble Film Packaging |
| Delivery Time: | 25 Working Days |
| Payment Terms: | T/T, D/A, L/C |
| Supply Ability: | 20 Sets Per Month |
|
Detail Information |
|||
| Available Capacity: | 5L-6000L | Tank Structure: | 3 Layers Of Steel, 2 Jackets |
|---|---|---|---|
| Material: | SUS316L/SUS304/SUS304 | Heating Method: | Electric Heating / Steam Heating |
| Cooling: | Tap Water / Ice Water Cooling | Mixing Method: | One Way Or Two Way Mixing With Teflon Scraper |
| Mixing Speed: | 0-65 R.p.m | Homogenizer Speed: | 0-3600 R.p.m |
| Control: | PLC&Touch Screen / Button | ||
| High Light: | Homogenizer Detergent Mixing Machine,Liquid Soap Detergent Mixing Machine,Lotion Homogenizer Emulsifier Mixer |
||
Product Description
Chemical Liquid Soap Homogenizer Detergent Mixing Machine Lotion Emulsifier Mixer
Brief Introduction:
Manufacturer of Cosmetic | Pharmacuetical | Food | Daily Chemical industrial | GMP Standard
It is mainly suitable for preparation of liquid detergents (such as Hand sanitizer, cleanser essence, shampoo and shower cream etc), integrating blending, dispersing, heating and cooling etc functions.
The reacting machine is an ideal device for liquid preparation in various factories.
The heating method is electrical heating or steam heating.
High speed homogenizer can mixing and disperse Viscously Solid and liquid raw material can dissolve material which is hard to dissolve such as AES, AESA LSA during liquid production which can save energy consumption and shorten production the and shorten production period.Main adopts stepless timing device which reduce babble occur under low temperature and highviscosity condition less air bubble will be formed to produce liquid washing products.Finished products can be discharged by Disc-valve or suitable to all liquid wash products.
The all-around wall scraping mixing adopts the frequency converter for speed adjustment, so that high quality products of
different processes according to customer requirements.
Technical Parameter:
| Capacity (L) | Homogenizer | Agitator | Vacuum pump | Heating system | ||||
| power (kw) | speed (rpm) | power (kw) | speed (rpm) | power (kw) | Limit vacuum | Electric heating (kw) | Steam heating (Mpa) | |
| 5 | 0.55 | 0-3600 | 0.4 | 0-65 | 0.37 | -0.1 | 6 | 0.2 |
| 10 | 1.1 | 0-3600 | 0.55 | 0-65 | 0.37 | -0.1 | 6 | 0.2 |
| 20 | 1.5 | 0-3600 | 0.55 | 0-65 | 0.37 | -0.1 | 9 | 0.2 |
| 50 | 3 | 0-3600 | 0.75 | 0-65 | 0.75 | -0.1 | 12 | 0.2 |
| 100 | 4 | 0-3600 | 1.5 | 0-65 | 1.5 | -0.1 | 24 | 0.2 |
| 200 | 5.5 | 0-3600 | 1.5 | 0-65 | 2.2 | -0.1 | 28 | 0.2 |
| 300 | 7.5 | 0-3600 | 3 | 0-65 | 2.2 | -0.1 | 32 | 0.2 |
| 500 | 11 | 0-3600 | 4 | 0-65 | 4 | -0.1 | 50 | 0.2 |
| 1000 | 15 | 0-3600 | 5.5 | 0-65 | 4 | -0.1 | 54 | 0.2 |
| 2000 | 18.5 | 0-3600 | 7.5 | 0-65 | 5.5 | -0.1 | recommend steam heating | 0.2 |
| 5000 | 22.5 | 0-3600 | 15 | 0-65 | 7.5 | -0.1 | 0.2 | |
| The parameters are for reference only, all the machines can be customized according to your needs. | ||||||||
Cosmetic Homogenizer Chemical Mixing Tank Detergent Making Machine, Dishwashing Liquid Mixer Shampoo Making Machine Price
Optional Configuration:
1. The blending system adopts single-direction or double direction s craping blending and frequency conversion speed adjustment,so as to satisfy product of different technological requirements
2. According to technological requirements, the materials can be heated or cooled. The heating method can be chosen steam or electric heating according to customer.
3. Various forms of blending vanes are suitable for production of different types of products.
4. Made of imported SUS304 or SUS306L stainless steel. The tank body and pipe are carried out mirror polishing.
5. Bottom installation type dispersing head and FLUKO pipeline type emulsifying head are optional to speedup dissolution and emulsification of materials.
6. The stainless steel electric control cabinet can completely supervise the operation of equipment, and display data, such
temperature and blending rotation speed etc.
Application Product:
* Cosmetics: lotions, sunscreen products, perfumes, decorative cosmetics, shampoos, hair dyes, hand lotions, liquid soaps, toothpastes, collagen suspensions, carbon emulsions
* Chemical Industry: detergents, polishes, lubricants, pigments, lacquers, preservatives, solvents, wax emulsions, polymer
emulsions, emulsions, glue solution, catalyst suspoemulsion, titanium dioxide suspoemulsion, penetrant, insecticide, fungicide
* Food: honey, soy sauce, condiments, mayonnaise, cheese, instant food, baby food, jam, pet food, starch solution
* Beverages: juice, vegetable juice, milk mixed drinks, protein drinks, spices, liqueurs, alginate
* Pharmaceutical Industry: ointment, gel, eye drops, cough syrup, injection solution, sugar/salt solution, suppository, sugar coating, shampoo, paraffin emulsion, fat emulsion, decomposition of vegetable ingredients Agent, preservative, serum, vaccine
