PLC Control Daily Chemical Homogenizer Hand Mouthwash Gel Lotion Emulsifier Mixer
Product Details:
| Place of Origin: | China |
| Brand Name: | LIANHE |
| Certification: | TUV, CE, SGS, GMP |
| Model Number: | PMC-1000L, PMC-2000L |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Plywood Case / Bubble Film Packaging |
| Delivery Time: | 25 Working Days |
| Payment Terms: | T/T, D/A, L/C |
| Supply Ability: | 20 Sets Per Month |
|
Detail Information |
|||
| Available Capacity: | 5L-6000L | Tank Structure: | 3 Layers Of Steel, 2 Jackets |
|---|---|---|---|
| Material: | SUS316L/SUS304/SUS304 | Heating Method: | Electric Heating / Steam Heating |
| Cooling: | Tap Water / Ice Water Cooling | Mixing Method: | One Way Or Two Way Mixing With Teflon Scraper |
| Mixing Speed: | 0-65 R.p.m | Homogenizer Speed: | 0-3600 R.p.m |
| Control: | PLC&Touch Screen / Button | ||
| High Light: | PLC Control Daily Chemical Homogenizer,Mouthwash Gel Daily Chemical Homogenizer,SUS304 Homogenizer Emulsifier Mixer |
||
Product Description
Daily Chemical Homogenizer Hand Mouthwash Mixing Machine Gel Lotion Emulsifier Mixer
Brief Introduction:
Manufacturer of Cosmetic | Pharmacuetical | Food | Daily Chemical industrial | GMP Standard
High speed homogenizer can mixing and disperse Viscously Solid and liquid raw material can dissolve material which is hard to dissolve such as AES, AESA LSA during liquid production which can save energy consumption and shorten production the and shorten production period.Main adopts stepless timing device which reduce babble occur under low temperature and highviscosity condition less air bubble will be formed to produce liquid washing products.Finished products can be discharged by Disc-valve or suitable to all liquid wash products.
The all-around wall scraping mixing adopts the frequency converter for speed adjustment, so that high quality products of
different processes according to customer requirements.
The diversified high-speed homogenizer can powerfully mix solid and liquid raw materials and can rapidly dissolve many
indissoluble materials such as AES, AESA, LSA,etc.during the liquid detergent production period.
The pot body is welded by imported three-layer stainless steel plate.the tank body and the pipes adopt mirror polishing, which fully conforms to GMP requirements
According to customer requirement, the tank can heat and cool materials the heating way including steam heating and electric heating.easy to discharge,bottom direct discharge or by transfer pump.
Technical Parameter:
| Capacity (L) | Homogenizer | Agitator | Vacuum pump | Heating system | ||||
| power (kw) | speed (rpm) | power (kw) | speed (rpm) | power (kw) | Limit vacuum | Electric heating (kw) | Steam heating (Mpa) | |
| 5 | 0.55 | 0-3600 | 0.4 | 0-65 | 0.37 | -0.1 | 6 | 0.2 |
| 10 | 1.1 | 0-3600 | 0.55 | 0-65 | 0.37 | -0.1 | 6 | 0.2 |
| 20 | 1.5 | 0-3600 | 0.55 | 0-65 | 0.37 | -0.1 | 9 | 0.2 |
| 50 | 3 | 0-3600 | 0.75 | 0-65 | 0.75 | -0.1 | 12 | 0.2 |
| 100 | 4 | 0-3600 | 1.5 | 0-65 | 1.5 | -0.1 | 24 | 0.2 |
| 200 | 5.5 | 0-3600 | 1.5 | 0-65 | 2.2 | -0.1 | 28 | 0.2 |
| 300 | 7.5 | 0-3600 | 3 | 0-65 | 2.2 | -0.1 | 32 | 0.2 |
| 500 | 11 | 0-3600 | 4 | 0-65 | 4 | -0.1 | 50 | 0.2 |
| 1000 | 15 | 0-3600 | 5.5 | 0-65 | 4 | -0.1 | 54 | 0.2 |
| 2000 | 18.5 | 0-3600 | 7.5 | 0-65 | 5.5 | -0.1 | recommend steam heating | 0.2 |
| 5000 | 22.5 | 0-3600 | 15 | 0-65 | 7.5 | -0.1 | 0.2 | |
| The parameters are for reference only, all the machines can be customized according to your needs. | ||||||||
stainless steel mixing tank could be used in food, beverage, pharmacy, chemical industry,wine and alcohol etc industries.
The inside surface finish of stainless steel mixing tank is Mirror polished, Ra<0.4um.
The welding are polished to ground smooth.
There are various agitator options of stainless steel mixing tank: impeller type, Anchor type, Turbine type, High shear
mixer,magnetic mixer. The mixing tank could be made with or without jacket.
stainless steel food grade mixing tank could be made with or without jacket. Jacket type including full jacket, Dimple
jacket,Heating coils. Heating and cooling type including steam heating and electric heating.
Optional Configuration:
1.Quick open manhole .
2.Various types of CIP cleaners .
3.Fly and insect resistant sanitary breathing cover .
4.Adjustable triangular bracket .
5.Dismountable materials input pipe assembly .
6.Thermometer (According to customer requirements ).
7.Ladder (According to customer requirements).
8.Paddle blender .
9.Liquid level meter and lever controller (According to customer requirements) .
10.Eddy-proof board .
Application Product:
* Cosmetics: lotions, sunscreen products, perfumes, decorative cosmetics, shampoos, hair dyes, hand lotions, liquid soaps, toothpastes, collagen suspensions, carbon emulsions
* Chemical Industry: detergents, polishes, lubricants, pigments, lacquers, preservatives, solvents, wax emulsions, polymer
emulsions, emulsions, glue solution, catalyst suspoemulsion, titanium dioxide suspoemulsion, penetrant, insecticide, fungicide
* Food: honey, soy sauce, condiments, mayonnaise, cheese, instant food, baby food, jam, pet food, starch solution
* Beverages: juice, vegetable juice, milk mixed drinks, protein drinks, spices, liqueurs, alginate
* Pharmaceutical Industry: ointment, gel, eye drops, cough syrup, injection solution, sugar/salt solution, suppository, sugar coating, shampoo, paraffin emulsion, fat emulsion, decomposition of vegetable ingredients Agent, preservative, serum, vaccine
