Shampoo Chemical Liquid Homogenizer Emulsifier Mixer Industrial Mixing Tank
Product Details:
| Place of Origin: | China |
| Brand Name: | LIANHE |
| Certification: | TUV, CE, SGS, GMP |
| Model Number: | PMC-1000L, PMC-2000L |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Plywood Case / Bubble Film Packaging |
| Delivery Time: | 35 Working Days |
| Payment Terms: | T/T, D/A, L/C |
| Supply Ability: | 20 Sets Per Month |
|
Detail Information |
|||
| Available Capacity: | 5L-6000L | Tank Structure: | 3 Layers Of Steel, 2 Jackets |
|---|---|---|---|
| Material: | SUS316L/SUS304/SUS304 | Heating Method: | Electric Heating / Steam Heating |
| Cooling: | Tap Water / Ice Water Cooling | Mixing Method: | One Way Or Two Way Mixing With Teflon Scraper |
| Mixing Speed: | 0-65 R.p.m | Homogenizer Speed: | 0-3600 R.p.m |
| Control: | PLC&Touch Screen / Button | ||
| High Light: | Chemical Liquid Homogenizer Emulsifier Mixer,Shampoo Homogenizer Emulsifier Mixer,3600rpm Homogenizer Emulsifier Mixer |
||
Product Description
Chemical Liquid Homogenizer Industrial Mixing Tank Shampoo Lotion Emulsifier Mixer
Brief Introduction:
Manufacturer of Cosmetic | Pharmacuetical | Food | Daily Chemical industrial | GMP Standard
Cosmetic industrial liquid detergent homogenizing mixer machine
Homogenizing mixer machine has high-speed disperser, mixing and disperse viscously, solid and liquid, etc. various kind of raw material will be dissolved which is such as AES, AESA LSA, during liquid production which can save energy consumption and shorten production the and shorten production period. To produce liquid washing products, like shampoo, liquid soap, bath shower, dishwashing, hand washing, lubricating oil, etc.
Technical Parameter:
| Capacity (L) | Homogenizer | Agitator | Vacuum pump | Heating system | ||||
| power (kw) | speed (rpm) | power (kw) | speed (rpm) | power (kw) | Limit vacuum | Electric heating (kw) | Steam heating (Mpa) | |
| 5 | 0.55 | 0-3600 | 0.4 | 0-65 | 0.37 | -0.1 | 6 | 0.2 |
| 10 | 1.1 | 0-3600 | 0.55 | 0-65 | 0.37 | -0.1 | 6 | 0.2 |
| 20 | 1.5 | 0-3600 | 0.55 | 0-65 | 0.37 | -0.1 | 9 | 0.2 |
| 50 | 3 | 0-3600 | 0.75 | 0-65 | 0.75 | -0.1 | 12 | 0.2 |
| 100 | 4 | 0-3600 | 1.5 | 0-65 | 1.5 | -0.1 | 24 | 0.2 |
| 200 | 5.5 | 0-3600 | 1.5 | 0-65 | 2.2 | -0.1 | 28 | 0.2 |
| 300 | 7.5 | 0-3600 | 3 | 0-65 | 2.2 | -0.1 | 32 | 0.2 |
| 500 | 11 | 0-3600 | 4 | 0-65 | 4 | -0.1 | 50 | 0.2 |
| 1000 | 15 | 0-3600 | 5.5 | 0-65 | 4 | -0.1 | 54 | 0.2 |
| 2000 | 18.5 | 0-3600 | 7.5 | 0-65 | 5.5 | -0.1 | recommend steam heating | 0.2 |
| 5000 | 22.5 | 0-3600 | 15 | 0-65 | 7.5 | -0.1 | 0.2 | |
| The parameters are for reference only, all the machines can be customized according to your needs. | ||||||||
1. The Omnidirectional wall scraping and mixing adopts a frequency converter to adjust the speed. At low temperatures and high
viscosity, it can reduce the formation of bubbles.
2. Jacket heating and cooling function (steam/electric heating)
3. The pot body is welded by three layers of stainless steel plates, mirror polished, in line with GMP requirements.
4. High-speed shearing homogenizer 3600rpm, strong mixing of solid and liquid raw materials.
5. Schneider switch control button, Delta inverter, Omron temperature control
stainless steel mixing tank could be used in food, beverage, pharmacy, chemical industry,wine and alcohol etc industries.
The inside surface finish of stainless steel mixing tank is Mirror polished, Ra<0.4um.
The welding are polished to ground smooth.
There are various agitator options of stainless steel mixing tank: impeller type, Anchor type, Turbine type, High shear
mixer,magnetic mixer. The mixing tank could be made with or without jacket.
stainless steel food grade mixing tank could be made with or without jacket. Jacket type including full jacket, Dimple
jacket,Heating coils. Heating and cooling type including steam heating and electric heating.
Optional Configuration:
Ø Reactor system (stainless steel and glass optional)
Ø Emulsifying system (optional for emulsifying and homogenizing head)
ØMixing system (digital display timing mixer optional)
ØTemperature control system (temperature probe optional)
Ø Lifting system (pneumatic assist and electric lift optional)
ØVacuum system (vacuum pump)
Ø Heating system (water bath or oil bath)
ØOnline monitoring system
Stainless Steel Emulsifying Mixing Tank 100l 200l 500l 1000l 2000l 5000l High Shear homogenizer chemical Industrial Mixing Tank
LIANHE 1000l cream homogenizer 1000l lotion making machine to cosmetic manufacturer by wooden case.
Application Product:
* Cosmetics: lotions, sunscreen products, perfumes, decorative cosmetics, shampoos, hair dyes, hand lotions, liquid soaps, toothpastes, collagen suspensions, carbon emulsions
* Chemical Industry: detergents, polishes, lubricants, pigments, lacquers, preservatives, solvents, wax emulsions, polymer
emulsions, emulsions, glue solution, catalyst suspoemulsion, titanium dioxide suspoemulsion, penetrant, insecticide, fungicide
* Food: honey, soy sauce, condiments, mayonnaise, cheese, instant food, baby food, jam, pet food, starch solution
* Beverages: juice, vegetable juice, milk mixed drinks, protein drinks, spices, liqueurs, alginate
* Pharmaceutical Industry: ointment, gel, eye drops, cough syrup, injection solution, sugar/salt solution, suppository, sugar coating, shampoo, paraffin emulsion, fat emulsion, decomposition of vegetable ingredients Agent, preservative, serum, vaccine
