Length 50-210mm Tube Filling Machine Antirusting For Cosmetic
Product Details:
| Place of Origin: | China |
| Brand Name: | LIANHE |
| Certification: | CE , ISO , SGS , TUV |
| Model Number: | LH-FS |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Contact Us |
| Packaging Details: | Normally packaged in wooden case or wrapping film, also can be customized |
| Delivery Time: | 20 working days |
| Payment Terms: | T/T, L/C, D/A, D/P, Cash |
| Supply Ability: | 30 Sets per Month |
|
Detail Information |
|||
| Material: | SUS304/316L | Filling Range: | 5-150m; 25-250ml; 30-500ml, Etc, Customized |
|---|---|---|---|
| Tube Length: | 50-210 Mm | Batch Printing: | Available |
| Key Selling Points: | High-Accuracy | Function: | Automatic Positioning, Filling, Heating, Sealing |
| High Light: | 50mm Tube Filling Machine,210mm Tube Filling Machine,Antirusting Cosmetic Tube Filling Machine |
||
Product Description
Fully Automatic Cream Plastic Tube Filling And Sealing Machine
Product Description:
Our automatic tube filling sealing machine is applicable to the pharmaceutical, food, cosmetics, daily chemical industry, the aluminum pipe for filling and sealing. Can all mushy, paste and viscous fluid and the material smooth accurately into the tube, and complete folding, sealing, batch number, production date.
This automatic packaging machine is used for fling facial cleanser, toothpaste,hand cream and sealing containers.It is widely used in food, cosmetics, pharmaceutical industries.The material of the container should be plastic, if you need the machine for aluminum material, please send us message.
Product Parameters:
|
Filling volume |
5-30ml; 6-60ml; 10-120ml; 30-200ml, 50-500ml, etc, customized |
|
Filling accuracy |
≤± 0.5-1% |
|
Capacity |
30-40 tubes per minute / 60-70tubes per minute |
|
Tube diameter |
OD 10-50mm |
|
Tube length |
210mm(Max. length) |
|
Hopper volume |
40L |
|
Power |
220V/380V, can be customized |
|
Air pressure |
1.1KW |
|
Equipped motor |
0.5-0.7Mpa |
|
Convulsions |
0.37KW |
|
Hot air |
3KW |
Product Application:
The tube filling and sealing machine is suitable for automatic color code aligning, filling, sealing, date printing and end cutting of various plastic tubes and aluminum composite tubes. It is widely applied in daily chemical industry, medicine, food, etc.
Product Advantages:
Auto Tube Orientation
Using high sensitivity Japan-Imported Panasonic infrared positioning system, plastic tube will be turning to right side according to the mark on the tube
Auto Ultrasonic Sealing & Coding Function
Using Japan ultrasonic technology, sealing the plastic tube and coding on it.
Auto Cutting Function
It's with the function of automatically cutting after sealing and coding, in which guarantee the tube tail more beauty.
Inported AirTAC Solenoid Valve
Adopting famous brand AirTac air system, greatly make the machine pressure working precisely.
Product Features:
1.It adopts Ultrasonic sealing machine , good for difference products, Such as food, medical, cosmetic products. It will not hurting the products.
2. Overload protection, phase separation protection, power-fail protection.
3. Large Ultrasonic output power to ensure the sealing quality of various tube size and material.
4. With tube end trimming
5. Easy change working mold for difference tube diameter
6. Adjustable tube length
7. Machine include a gear pump filler( Good filling precision+- 1)
Product Details:
Our Servers:
We provide Turn-key project service to customer.
1. Factory Layout design;
2. Factory Decoration based on GMP standard;
3. Formula of products;
4. Raw material etc;
5. Machine design, whole production line from A to Z;
6. Shipping service, FOB, CFR, CIF etc;
7. Installation service. Training service, Mainte
