SUS304 Cosmetic Mixing Tank
Product Details:
| Place of Origin: | China |
| Brand Name: | LIANHE |
| Certification: | CE, TUV, SGS, GMP |
| Model Number: | PMC-500L |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Plywood Case / Bubble Film Packaging |
| Delivery Time: | 30 Working Days |
| Payment Terms: | T/T, D/A, L/C |
| Supply Ability: | 20 Sets Per Month |
|
Detail Information |
|||
| Available Capacity: | 30L To 6000L | Tank Structure: | 3 Layers Of Steel, 2 Jacket |
|---|---|---|---|
| Material: | SUS316L/SUS304/SUS304 | Heating Method: | Electric Heating / Steam Heating |
| Cooling: | Water Cooling | Mixing Method: | One Way Or Two Way Mixing With Teflon Scraper |
| Mixing Speed: | 0-65RPM | Homogenizer Speed: | 3000RPM |
| Highlight: | SUS304 Cosmetic Mixing Tank,Vacuum Cosmetic Mixing Tank,PLC Vacuum Emulsifying Machine |
||
Product Description
500L High Shear New Material Making Heating Tank Liquid Mixer Emulsifier
Brief Introduction:
The mixing blade is driven by the power unit to rotate in a fixed direction; during the rotation process, the material is driven to rotate axially and radially.
The fixed paddles break up the vortex created during the mixing process, ensuring that all the raw materials in the jar get a better mix.
The materials in the mixer have axial motion and circular motion at the same time, so there are several stirring forms such as shear stirring and diffusion stirring at the same time. It can effectively stir and mix materials quickly.
Through high-speed operation of the dispersing disc, the material flows in an annular shape, generating a strong vortex, which descends to the bottom of the vortex in a spiral shape. Strong shearing impact and friction are generated between the particles to achieve rapid dispersion and dissolution. The circular motion of the stirring plate produces a good radial effect, which accelerates the plastic circulation and improves the dispersion efficiency.
Technical Parameter:
|
Model |
Capacity (L) |
Agitator |
Homiogenizer |
Heating system |
|||
|
power (kw) |
speed (rpm) |
power (kw) |
speed (rpm) |
Electric heating (kw) |
Steam heating (Mpa) |
||
|
PMC-50 |
50 |
0.75 |
0-65 |
3 |
3000 |
6 |
Steam heating energy conservation and environmental protection, selected according to need |
|
PMC-100 |
100 |
1.5 |
0-65 |
4 |
3000 |
9 |
|
|
PMC-150 |
150 |
1.5 |
0-65 |
4 |
3000 |
12 |
|
|
PMC-200 |
200 |
1.5 |
0-65 |
4 |
3000 |
12 |
|
|
PMC-300 |
300 |
1.5 |
0-65 |
5.5 |
3000 |
18 |
|
|
PMC-500 |
500 |
2.2 |
0-65 |
7.5 |
3000 |
27 |
|
|
PMC-1000 |
1000 |
4 |
0-65 |
11 |
3000 |
36 |
|
|
PMC-1500 |
1500 |
5.5 |
0-65 |
15 |
3000 |
45 |
|
|
PMC-2000 |
2000 |
7.5 |
0-65 |
15 |
3000 |
recommend steam heating |
|
|
PMC-3000 |
3000 |
11 |
0-65 |
15 |
3000 |
||
|
PMC-5000 |
5000 |
11 |
0-65 |
22 |
3000 |
||
|
The parameters for reference only, all the machines can be customized accordingly. |
|||||||
Application Product:
1. Cosmetics industry: skin cream, shaving cream, sunscreen, facial cleanser, nutritional honey, dye cream, ion iron, hydrogen peroxide, etc., essence, moisturizing cream, hand cream, etc.
2. Daily chemical industry: detergent, shampoo, shower gel, conditioner, laundry detergent, hand sanitizer, toilet cleaning, car glass water, detergent, tire wax, cleaning cream, etc.
3. Pharmaceutical industry: latex, emulsion, various ointments (ointments), antibiotics, injections, oral syrups, oral liquids, gels, etc.
4. Food industry: jam, chili sauce, food slurry, condiment, cheese, nutrient solution, baby food, chocolate, sugar, etc.
5. Chemical industry: latex, saponified products, paints, coatings, resins, adhesives, New materials, etc.
6. Comprehensive: production equipment for various liquid products such as resin coatings, paints, shoe polish, chemical fibers, etc., supports a variety of liquid technologies, the machine has beautiful appearance, low noise, and is easy to move. The machine can be customized according to requirements, can be heated at a constant temperature, and can be selected from various styles of stirring blades.
Features:
The mixing tank can be equipped with 1-2 high-speed dispersers, emulsifiers, dispersers, and emulsification equipment as required.
The rotating speed can be as high as 3000rpm and the linear speed is more than 20m/s, which can quickly and uniformly disperse the powder into the liquid material. Due to the high shear force, the material is uniformly dispersed, forming a good suspension effect, and the state is stable.
Easy maintenance and cleaning.
The agitator and the main shaft are fixed with bolts, which is convenient to move and disassemble.
Strong non-standard, various types of non-standard products can be customized, such as explosion-proof type, airtight vacuum type, wall scraping type, multi-functionality, etc.
This machine can be customized 316L stainless steel or anti-corrosion spray treatment according to customer requirements.
