Leakproof Tube Packing Machine
Product Details:
| Place of Origin: | China |
| Brand Name: | LIANHE |
| Certification: | CE , ISO , SGS , TUV |
| Model Number: | LH-AFS |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Contact Us |
| Packaging Details: | Normally packaged in wooden case or wrapping film, also can be customized |
| Delivery Time: | 20 working days |
| Payment Terms: | T/T, L/C, D/A, D/P, Western Union, MoneyGram |
| Supply Ability: | 30 Sets per Month |
|
Detail Information |
|||
| Product Name: | Automatic Filling And Sealing Machine | Material: | Stainless Steel 304/316L |
|---|---|---|---|
| Control: | PLC + Servo Motor Control | Function: | Filling And Sealing |
| Packaging Material: | Plastic And Laminated Tube | Filling Speed: | 20-60 Tubes Per Minute Optional |
| Highlight: | Leakproof Tube Packing Machine,Automatic Tube Packing Machine,Anticorrosive Tube Filling Equipment |
||
Product Description
Automatic Tube Filling Machine Ointment Paste Filling and Sealing Machine
Product Description:
This machine is a high technical equipment which successfully developed and designed by introducing into advanced overseas technology and integrating GMP requirement. It adopts with PLC controller, automatically operating from liquid or high velocity material filling till batch number printing (include manufacture date), it's an ideal equipment for ALU tube, plastic tube and multiple tube filling and sealing in cosmetic, pharmacy, foodstuff, adhesives etc industries.
Product Parameters:
|
Filling volume |
5-250ml(tube) |
|
Filling accuracy |
≤±1% |
|
Capacity |
40 tubes/min(normal type); 60-70 tubes/min(high speed type) |
|
Tube diameter |
OD10-50mm |
|
Tube length |
210mm(Max. length) |
|
Hopper volume |
40L |
|
Power |
220V/380V, can be customized |
|
Air pressure |
1.1KW |
|
Equipped motor |
0.5-0.7Mpa |
|
Air feeding |
0.37KW |
|
Convulsions |
0.37KW |
|
Hot air |
3KW |
|
Dimension |
3KW |
|
Weight |
1800kg (approx) |
Product Application:
The tube filling and sealing machine is suitable for automatic color code aligning, filling, sealing, date printing and end cutting of various plastic tubes and aluminum composite tubes. It is widely applied in daily chemical industry, medicine, food, etc.
Product Features:
1. With 12 stations and matching with manipulator, the machine is able to meet different type of tail folding, sealing requirements of Alu tube. It is a multi-purpose machine.
2. Tube feeding, eye marking, tube interior cleaning (optional), material filling, sealing (tail folding), batch number printing, finished products discharging can be performed automatically (the whole procedure).
3. Servo control makes it precise and convenient to adjust the filling amount by touch screen.
4. According to the different length of the tube, height of tube chamber can be adjusted easily by motor. With external reversal feeding system, makes tube charging more convenient and tidy.
5. The mechanical linkage photo sensor precision tolerance is less than 0.2mm. The chromatic aberration scope between tube and eye mark is reduced.
6. Photo-electronic, electric, pneumatic integrative control is applied with the machine. No tube, no filling. It gives an alarm when low pressure occurs. The machine stops automatically if tube error or open the safety door.
7. Three-layer jacket instant heater with inside air heating, it won't damage the pattern on outer wall of tube and achieves firm and beautiful sealing effect.
Product Details:
